5.65 PiCu Isotherm Double Drawer 160 LIGHT FREEZER ONLY with ICE MAKER – Stainless Steel

5.65 PiCu Isotherm Double Drawer 160 LIGHT FREEZER ONLY with ICE MAKER – Stainless Steel

Name: 5.65 PiCu Isotherm Double Drawer 160 LIGHT FREEZER ONLY with ICE MAKER - Stainless Steel
SKU: 3160BP6C00017
Price: 4158.00 CAD
Availability: BackOrder

5.65 PiCu A high-capacity marine freezer designed for flush mount integration in yachts, RVs or expedition vehicles. It includes two independent drawers, fully stainless steel, and an integrated ice machine located in the top drawer. This model runs on 115 V AC and is part of the 'Drawer 160 Light' range, renowned for its reliability, silence and compact design.

Email us for a quote

Isotherm

Features

GENERAL:

Type: Freezer Only with Ice Maker
Mounting: Flush mount (flush mounted)
Number of drawers: 2 stainless steel drawers
Flange type: 4-sided flush mount flange.
Use : Single freezer with built-in automatic ice machine

Isotherm limited warranty 3 years on each compressor, 2 years warranty on parts.

Specifications

ELECTRIC

Supply voltage 115 V AC, 50/60 Hz

Compressor type Danfoss/ Secop BD50F (ventilated)

Typical consumption ~ 1.0 kWh / 24 h ( 1000 Wh/day)
Average current 0.9 A at 115 V AC

Electronic starting with low voltage safety

Integrated fuse protection and automatic electronic cut-off

DIMENSIONS:

Packaged height 37.0 in 94 cm

Packaged width 29.0 in 74 cm

Packed depth 28.0 in 71 cm

Gross weight (with packaging) 140 lb 63.5 kg

PERFORMANCE:

Freezer function only (two drawers with negative cold)

Freezing temperature Up to -18 °C (0 °F) at nominal conditions

Integrated ice machine, removable tray, automatic feeding

Insulation High-density polyurethane foam

Ventilation system Ventilated compressor, air cooling

Very low sound level ( < 38 dB(A))

Refrigerant R134a (or R600a according to recent version)
